Description
Package:
产品详情 Technical Parameters
产品型号 Model : JDPQ-2T-6C
主机箱尺寸 Silo Size : L1700*W1100*H1900mm
被子称重机尺寸 Quilt Weighing Machine Size: L1700*W650*H900mm
被子操作台尺寸 Quilt Filling Table Size: L1800*W1200*H740mm
枕头称重机尺寸 Pillow Weighing Machine Size:L1700*W800*H1000mm
枕头填充风机尺寸：Pillow Filling Fan Size: L1300*W900*H1150mm
净重 N.W.:1200kgs
占地面积：Working Area: L 13.7M*W 2.8M
储绒量 Material Storage Volume : 15-20kgs
额定功率 Rated Power : 7.8KW
设备电压 Equipment Voltage: AC380V/50HZ
设备进气要求 Equipment Input Air Pressure : 7-8 Bar
空压机功率/排气量 Screw Air Compressor Power/Exhaust : 7.5 kw 0.8m³/min ( Equipped By Customers), 8mm inner diameter air hose.
可填充材料 Filling Material : Goose Down /Duck Down/ 0-8cm long Feather /Ball Fiber/ Short Polyester Fiber ,Crush Foam , Above Mixing Material
充绒口数量 Number Of Filling Ports: 2
充绒口直径 Pile Filling Diameter: 60/80/100mm For Pillow , 38mm/51mm For Quilt/Mattress
称重循环数 Weighing Cycle Number : 1/2-1/4, total 6 weighing scales
填充范围 Filling Weighing Range: 1-120g For Quilt Per time, 5g-1000g For Pillow Per time
填充速度 Filling Capacity : 200Pcs Pillow(1000g) Per Hour , 720 Pockets For Quilt Per Hour
显示精度（90绒标准测试）Display Accuracy ( 90% Goose Down Testing) : 0.01g
误差范围 90绒标准测试）Precision Wave ( 90% Goose Down Testing) : ±2%
填充测试湿度 Filling Humidity Test : 65% RH 5%
备注 Note: Integral Filling Equipment Includes :1 Silo+1Quilt Weighing Machine+1 Quilt Filling Table+1 Pillow Weighing Machine+1 Pillow Filling Fan+1 Material Loading Fan
特殊功能 Special Function：
1，自动上料 Auto Feeding
2，自动称重 Auto Weighing
3，远程协助 Remote Assistance
4, 多退少补 Auto Move Back Overweight Material
5，一机多功能 One Machine Can Fill Pillow And Quilt At Same Time, Save Cost , Suitable For Pillow And Quilt Home Textile Producer Who Have Weighing Needs, And Also Meet To Fill Firm /Tight /Strong/Plump/Full Pillow.
*被子填充视频：Quilt Filling Video: https://youtu.be/JCWfQmipwNw
*自动上料视频：Auto Loading Material Video: https://youtu.be/O0YC0H-gNUU
